Mi TV P1 - 32'' 43'' 55''

Main Features • Limitless 4K Display, MEMC • Android TV™ • Hands-free Google Assistant • Smart Home Control Hub

Specifications Display • Display Type: 4K UHD • Resolution: 3,840 x 2,160 • Color gamut: NTSC 88% (typ), DCI-P3 94% (typ), BT709 99.5% (typ) • Color depth: 1.07 billion (8-Bit + FRC) • Refresh rate: 60Hz • MEMC: UHD 60Hz • Viewing angle: 178°(H)/178°(V)

• Dolby Vision® • HDR10+ • HLG

Speakers Supported Video Formats: • AV1, H.265, H.264, H.263, VP8/VP9, MPEG1/2, MJPEG Supported Audio Formats: • Dolby, DTS, FLAC, AAC, AC4, OGG, MPEG-I, MPEG-II, etc. Supported Image Formats: • PNG, Gif, JPG, Bmp Picture Mode: • Standard, Vivid, Sport, Movie, Monitor, HDR mode, etc.  Sound Mode: • Standard, Movie, News, Game, Custom

Connectivity • Bluetooth 5.0 • Wi-Fi 2.4GHz/5GHz • HDMI x 3（1 port with eARC) • USB 2.0 x 2 • Composite In (AV) • CI Slot • Ethernet (Lan) • Optical Digital Audio Out • 3.5mm headphone jack • Broadcasting system: DVB-T2/C, DVB-S2

Processor and Storage • Processor: MediaTek 9611 • CPU: Quad A55, up to 1.5GHz • GPU: Mali G52 MP2 • RAM: 2GB

• Storage: 16GB

Design • Size: 55” • Limitless display with no-bezel • Color: Black • Stand: double • Power button(in the bottom of the TV) • LED notification light: white color variable light • Microphone Mute switch

Dimensions & Weight 55" • Dimensions including base (L x W x H): 1234.9 x 285.3 x 782.2mm • Dimensions not including base (L x W x H): 1234.9 x 89.2 x 724.6mm • Packing size (L x W x H): 1350 x 152 x 837mm • Weight including base: 11.9kg • Weight not including base: 11.7kg • Packing weight:16kg

43" • Dimensions including base (L x W x H): 962 x 205 x 625mm • Dimensions not including base (L x W x H): 962 x 85 x 556mm • Packing size (L x W x H): 1070 x 140 x 650mm • Weight including base: 7.4kg • Weight not including base: 7.3kg • Packing weight: 9.8kg

32" • Dimensions including base (L x W x H): 733 x 180 x 479mm • Dimensions not including base (L x W x H): 733 x 80 x 435mm • Packing size (L x W x H): 830 x 128 x 520mm • Weight including base: 3.9kg + 45g • Weight not including base: 3.9kg • Packing weight: 5.2kg

• Supports wall mounting

• Power & Operating environment • Power: 150W • Voltage: 100-240V ~ 50/60Hz • Operating temperature 0℃～40℃, Humidity 20%～80% • Storage temperature -15℃～45℃, Relative humidity<80%

• Operating system • Android TV™ 10

Package Contents • 360° bluetooth remote control x1 | Screws bag x1 | Stand components x2 | User manual x1 | Warranty card x1 | Power cable x1
